| Model | WHP-050HC - 15KW | WHP-050HC - 15KW |
| Power Supply - Refrigerant | 220-240V/1PH/ 50Hz -R410A | 380-415V/3PH/ 50Hz -R410A |
| Heating Capacity ( KW ) - A | 15 | 15 |
| Rated Input Power ( KW ) - A | 4 | 4 |
| COP ( W/W ) - A | 3.75 | 3.75 |
| Heating Capacity ( KW ) - B | 10.8 | 11 |
| Rated Input Power ( KW ) - B | 4.27 | 4.31 |
| COP ( W/W ) - B | 2.53 | 2.55 |
| Cooling Capacity ( KW ) - C | 12 | 12 |
| Rated Input Power ( KW ) - C | 3.93 | 3.87 |
| EER ( W/W ) - C | 3.05 | 3.10 |
| Max. Input Power ( KW ) | 5.5 | 5.5 |
| Max. Input Current ( A ) | 25 | 8.3 |
| Compressor | Highly or Mitsubishi EVI Technology Twin Rotary | |
| Fan | DC inverter brushless fans | |
| Fan Quantity | 2 | 2 |
| Fan Airflow ( m3/h ) | 5000 | 5000 |
| Fan Rated Power ( W ) | 160 | 160 |
| Heat exchanger | High efficiency plate type heat exchanger | |
| WaterSide Pressure Drop ( Kpa ) | 39 | 39 |
| Inlet/Outlet Pipe Size ( mm ) | DN25 | DN25 |
| Min. Water Flow ( m3/H ) | >2.6 | >2.6 |
| Noise ( dB(A) ) | ≤56 | ≤56 |
| Heating Water Temp. ℃ | 20 ~ 60℃ | 20 ~ 60℃ |
| Cooling Water Temp. ℃ | 5 ~ 20 ℃ | 5 ~ 20 ℃ |
| Operating Ambient Temp. ℃ | -35°C~45℃ | -35°C~45℃ |
| Unit Dimension ( mm ) | 1100*400*1250 | 1100*400*1250 |
| Weight ( KG ) | 125/132 | 125/132 |
| Performance Condition - A ： Ambient temp. (DB/WB): 7°C/6°C, Water temp. (In/Out): 40°C/ 45°C; | ||
| Performance Condition - B ： Ambient temp. (DB/WB): -12°C/-14°C, Water temp. (Out): 41°C | ||
| Performance Condition - C： Ambient temp. (DB/WB): 35°C/24°C, Water temp. (In/Out): 12°C/7°C. | ||
